Copper Conductor
25 sqmm▼
Description
Hard Drawn Bare Copper Conductor of size 25 sqmm is manufactured using 99% pure copper and designed for high conductivity and mechanical strength.
Each strand has a diameter of 2.14 mm with a total of 7 strands, forming a conductor with an overall diameter of 6.42 mm.
This single-core, multi-stranded conductor is suitable for earthing and grounding applications, offering excellent durability and long service life. It is manufactured as per IS 3043 standards and supplied in lengths as per requirement.
Technical Data
| Manufacturer | Any Reputed Make |
| Product | Single Core Multi Stranded Bare Copper Cable |
| Type of Product | Hard Drawn Conductor |
| Size | 25 sqmm |
| Core Material | 99% Pure Copper |
| Make | Standard |
| ISI Marked | Yes |
| Dia of Each Strand | 2.14 mm |
| No of Strands | 7 |
| Overall Dia of Conductor | 6.42 mm |
| Standard Length of Coil | As per Requirement |
| Applicable Standard | IS 3043 |
