S-S-S(H) Exothermic Welding Mould for Strip to Strip Manufacturer in India
Graphite mould for straight horizontal strip to strip exothermic welded joints
.webp&w=3840&q=75)
Description
The S-S-S(H) Exothermic Welding Mould manufactured by SG Power Products Pvt. Ltd. is a "Straight" Type mould used for Earth Grid Strip to Earth Grid Strip connection. It produces a straight horizontal in-line connection by exothermic welding, forming a permanent molecular bond between the conductors without any external power source or mechanical connector.
The mould is machined from Graphite, which withstands the heat of the reaction and holds an accurate cavity shot after shot. It accepts a run strip of 20x3 mm to 50x8 mm and a tap strip of 20x3 mm to 50x8 mm, covering the earthing strip sizes normally used on site.
Each mould delivers Approx 40-60 Joints per Mold when cleaned and pre-heated correctly between welds. The joint is made for Exothermic Welding Joints for Earthings and complies with IEEE 837, NBC 2016, giving a connection that carries full fault current, will not loosen, and does not corrode over the life of the installation.
Technical Data — S-S-S(H)
| Model | S-S-S(H) |
| Joint Type | "Straight" Type |
| Product | Exothermic Welding Mould |
| Suitable for Joint | Earth Grid Strip to Earth Grid Strip connection |
| Suitable Strip (Run) | 20x3 mm to 50x8 mm |
| Suitable Strip (Tap) | 20x3 mm to 50x8 mm |
