S-C-S(H) Exothermic Welding Mould for Strip to Cable Manufacturer in India
Graphite mould for straight horizontal bus bar strip to cable exothermic welded joints
.webp&w=3840&q=75)
Description
The S-C-S(H) Exothermic Welding Mould manufactured by SG Power Products Pvt. Ltd. is a "Straight" Type Horizontal mould used for Bus Bar (Strip) to Cable connection. It produces a straight horizontal connection by exothermic welding, forming a permanent molecular bond between the strip and the cable without any external power source or mechanical connector.
The mould is machined from Graphite, which withstands the heat of the reaction and holds an accurate cavity shot after shot. It accepts a strip of 20x3 mm to 50x8 mm and a cable of 35 sqmm to 300 sqmm, covering the bus bar and conductor sizes normally used on site.
Each mould delivers Approx 40-60 Joints per Mold when cleaned and pre-heated correctly between welds. The joint is made for Exothermic Welding Joints for Earthings and complies with IEEE 837, NBC 2016, giving a connection that carries full fault current, will not loosen, and does not corrode over the life of the installation.
Technical Data — S-C-S(H)
| Model | S-C-S(H) |
| Joint Type | "Straight" Type Horizontal |
| Product | Exothermic Welding Mould |
| Suitable for Joint | Bus Bar (Strip) to Cable connection |
| Suitable Strip Size | 20x3 mm to 50x8 mm |
| Suitable Cable Size | 35 sqmm to 300 sqmm |
