R-S-T Exothermic Welding Mould for Rod to Strip Manufacturer in India
Graphite mould for T type riser earth grid rod to strip exothermic welded joints
Description
The R-S-T Exothermic Welding Mould manufactured by SG Power Products Pvt. Ltd. is a "T" Type (Riser) mould used for Earth Grid Rod to Strip (Riser) connection. It produces a tee riser connection by exothermic welding, forming a permanent molecular bond between the rod and the strip without any external power source or mechanical connector.
The mould is machined from Graphite, which withstands the heat of the reaction and holds an accurate cavity shot after shot. It accepts an earth rod of 12 mm to 32 mm diameter and a strip of 20x3 mm to 65x10 mm, covering the rod and bus bar sizes normally used on site.
Each mould delivers Approx 40-60 Joints per Mold when cleaned and pre-heated correctly between welds. The joint is made for Exothermic Welding Joints for Earthings and complies with IEEE 837, NBC 2016, giving a connection that carries full fault current, will not loosen, and does not corrode over the life of the installation.
Technical Data — R-S-T
| Model | R-S-T |
| Joint Type | "T" Type (Riser) |
| Product | Exothermic Welding Mould |
| Suitable for Joint | Earth Grid Rod to Strip (Riser) connection |
| Suitable Rod Dia | 12 mm to 32 mm |
| Suitable Strip Size | 20x3 mm to 65x10 mm |
