R-C-T Exothermic Welding Mould for Rod to Cable Manufacturer in India
Graphite mould for T type riser earth rod to cable exothermic welded joints
%20Riser-01.webp&w=3840&q=75)
Description
The R-C-T Exothermic Welding Mould manufactured by SG Power Products Pvt. Ltd. is a "T" Type Riser mould used for Earth Rod to Earth Grid Conductor (Cable) connection. It produces a tee riser connection by exothermic welding, forming a permanent molecular bond between the rod and the conductor without any external power source or mechanical connector.
The mould is machined from Graphite, which withstands the heat of the reaction and holds an accurate cavity shot after shot. It accepts a rod dia of 12 mm to 32 mm and a cable size of 35 sqmm to 300 sqmm, covering the earth rod and conductor sizes normally used on site.
Each mould delivers Approx 40-60 Joints per Mold when cleaned and pre-heated correctly between welds. The joint is made for Exothermic Welding Joints for Earthings and complies with IEEE 837, NBC 2016, giving a connection that carries full fault current, will not loosen, and does not corrode over the life of the installation.
Technical Data — R-C-T
| Model | R-C-T |
| Joint Type | "T" Type Riser |
| Product | Exothermic Welding Mold |
| Suitable for Joint | Earth Rod to Earth Grid Conductor (Cable) connection |
| Suitable Rod Dia | 12 mm to 32 mm |
| Suitable Cable Size | 35 sqmm to 300 sqmm |
