GI Mast

GI Mast
GI Mast Drawing

Description

The GI Mast manufactured by SG Power Products Pvt. Ltd. is a robust and reliable structural support used in lightning protection systems for mounting air terminals, lighting arresters, and other equipment at elevated heights.

Made from high-quality Galvanized Iron (GI), the mast offers excellent strength, durability, and resistance to corrosion, making it suitable for outdoor installations in harsh environmental conditions.

This mast features a 48 mm diameter pipe with a total length of 6 and 3 meters, ensuring optimal height for effective lightning interception. It comes with a sturdy 300x300x6 mm base plate for secure mounting and stability.

Designed as a single-piece structure, the GI mast ensures easy installation, minimal maintenance, and long-term performance in standard-grade applications.

Technical Data

ManufacturerSG Power Products Pvt. Ltd.
ProductGI Mast
MakeSGPL
MATERIAL DESCRIPTIONGI
DIA OF MAST48 ±2 mm
LENGTH6 mtr
NO OF PIPE1 PIPES
LENGTH OF PIPE6 MTR
GRADE OF PIPESTANDARD
BASE PLATE300x300x6 mm
