Light Duty Pit Cover EPC T6

Earth Pit Cover Model EPC T6
Earth Pit Cover EPC-t6 Drawing

Description

The TRUESAFEâ„¢ Earth Pit Cover (Model EPC - T6) manufactured by SG Power Products Pvt. Ltd. is a light-duty protective enclosure designed to safeguard earthing systems from physical damage, environmental exposure, and unauthorized access. Made from high-quality HDPP (High-Density Polypropylene), it ensures excellent durability, corrosion resistance, and long-lasting performance in outdoor conditions.

This model features a round shape with a top diameter of 165 mm, bottom diameter of 245 mm, and a height of 250 mm, providing a secure and stable installation over earthing pits. It is equipped with a rotation locking lid system for enhanced safety and ease of maintenance. The cover includes 2 openings for earthing conductors, ensuring flexible installation. With UV resistance, eco-friendly construction, and compliance with IS 3043 standards, the EPC-T6 is ideal for residential, light commercial, and general-purpose earthing applications.

Technical Data

ManufacturerSG Power Products Pvt. Ltd.
ProductTRUESAFEâ„¢ Earth Pit Cover
ModelEPC - T6
MakeSGPL
Material UsedHDPP
Bottom ColorBlack
Lid ColorGreen
ShapeRound
Top Dia165 mm
Bottom Dia245 mm
Height250 mm
Lid Lock SystemYes (Rotation Locking)
UV ResistentYes
Eco FriendlyYes
No of Openings2 openings for Earthing conductor
Applicable StandardIS3043
