Light Duty Pit Cover EPC 2L
Description
The TRUESAFEâ„¢ Earth Pit Cover (Model EPC - 02L) manufactured by SG Power Products Pvt. Ltd. is a light-duty protective enclosure designed to safeguard earthing systems from external damage, environmental exposure, and unauthorized access. Made from high-quality HDPP (High-Density Polypropylene), the cover offers excellent durability, corrosion resistance, and long service life for outdoor applications.
This model features a round design with a top diameter of 240 mm and bottom diameter of 340 mm, along with a height of 265 mm, ensuring a secure and stable fit over earthing pits. It is equipped with a rotation locking lid system for easy handling and safety. The cover includes 2 openings for earthing conductors, allowing flexible installation. With UV resistance, eco-friendly construction, and compliance with IS 3043 standards, the EPC-02L is ideal for residential, light commercial, and general-purpose earthing applications.
Technical Data
| Manufacturer | SG Power Products Pvt. Ltd. |
| Product | TRUESAFEâ„¢ Earth Pit Cover |
| Model | EPC - 02L |
| Make | SGPL |
| Material Used | HDPP |
| Bottom Color | Black |
| Lid Color | Green |
| Shape | Round |
| Top Dia | 240 mm |
| Bottom Dia | 340 mm |
| Height | 265 mm |
| Lid Lock System | Yes (Rotation Locking) |
| UV Resistent | Yes |
| Eco Friendly | Yes |
| No of Openings | 2 openings for Earthing conductor |
| Applicable Standard | IS3043 |
