Heavy Duty Pit Cover EPC 3
Description
The TRUESAFEâ„¢ Earth Pit Cover (Model EPC - 03) manufactured by SG Power Products Pvt. Ltd. is a heavy-duty protective enclosure designed to safeguard earthing systems from physical damage, environmental exposure, and unauthorized access. Made from high-quality HDPP (High-Density Polypropylene), the cover ensures excellent strength, corrosion resistance, and long-lasting performance in demanding outdoor and industrial environments.
The cover features a round design with a top diameter of 260 mm, bottom diameter of 350 mm, and a height of 365 mm, providing a secure and stable fit over earthing pits. It is equipped with a GI hex bolt lid locking system to prevent tampering and enhance safety. The product includes four openings for earthing conductors, allowing flexible installation. With UV resistance, eco-friendly construction, and compliance with IS 3043 standards, the EPC-03 is ideal for industrial, commercial, and infrastructure applications requiring reliable earthing protection.
Technical Data
| Manufacturer | SG Power Products Pvt. Ltd. |
| Product | TRUESAFEâ„¢ Earth Pit Cover |
| Model | EPC - 03 |
| Make | SGPL |
| Material Used | HDPP |
| Bottom Color | Black |
| Lid Color | Green |
| Shape | Round |
| Top Dia | 260 mm |
| Bottom Dia | 350 mm |
| Height | 365 mm |
| Lid Lock System | Yes (GI Hex Bolt) |
| UV Resistent | Yes |
| Eco Friendly | Yes |
| No of Openings | 4 openings for Earthing conductor |
| Applicable Standard | IS3043 |
