Heavy Duty Pit Cover EPC 2
Description
The TRUESAFEâ„¢ Earth Pit Cover (Model EPC - 02) manufactured by SG Power Products Pvt. Ltd. is a heavy-duty protective enclosure designed to safeguard earthing systems from physical damage, environmental exposure, and unauthorized access. Made from high-quality HDPP (High-Density Polypropylene), the pit cover offers excellent durability, corrosion resistance, and long service life even in harsh outdoor conditions.
The cover features a round design with a top diameter of 240 mm, bottom diameter of 320 mm, and a height of 275 mm, ensuring easy installation and secure fitting over earthing pits. It is equipped with a lid locking system using an Allen bolt to prevent tampering and enhance safety. The product includes four openings for earthing conductors, making it suitable for various installation requirements. With UV resistance and eco-friendly construction, the EPC-02 complies with IS 3043 standards and is ideal for industrial, commercial, and infrastructure applications.
Technical Data
| Manufacturer | SG Power Products Pvt. Ltd. |
| Product | TRUESAFEâ„¢ Earth Pit Cover |
| Model | EPC - 02 |
| Make | SGPL |
| Material Used | HDPP |
| Bottom Color | Green / Black |
| Lid Color | Green |
| Shape | Round |
| Top Dia | 240 mm |
| Bottom Dia | 320 mm |
| Height | 275 mm |
| Lid Lock System | Yes (Allen Bolt) |
| UV Resistent | Yes |
| Eco Friendly | Yes |
| No of Openings | 4 openings for Earthing conductor |
| Applicable Standard | IS3043 |
